Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction

Brand Name : HCGG

Model Number : HSS001

Certification : CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001

Place of Origin : Henan,China

MOQ : 50 square meters

Price : USD20-100 Square Meter/Negotiable

Payment Terms : L/C,T/T,Western Union,.pay

Supply Ability : 50000 Tons/year

Delivery Time : 20-50days

Packaging Details : Conventional sea freight packing;Steel pallets

Product Type : Steel Structure Warehouse

Main Structurel Material : Q355B/ASTM A572 Gr.50/EN S355/JIS SM490

Secondary Structurel Material : Q235B / ASTM A36/ EN S235JR / JIS SS400

Other Material : Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570

Customization : Style,size,Color,Material

After-sale Service : Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support

Project Solution Capability : CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply

Column and Beam : Welded H-section/Hot-rolled H-beam/Box column

Purlin : C.Z Shape Steel Channel

Roof and Wall panel : EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized/

Window : Aluminum alloy / PVC /Industrial louver window

Door : Sliding/Rolling shutter/Hinged steel/Customized steel door

Surface treatment : Hot-dip galvanized Zinc-rich primer + top coat Anti-corrosion coating

Service Life : 20-50 Years

Life Span : More Than 50 Years

Contact Now

High Strength Multi Storey Steel Structure Building
Heavy steel structures are engineered load-bearing systems designed to withstand extremely heavy loads and significant spans/heights. Industry standards typically define these structures by plate thickness ≥20mm, single-piece weight ≥10 tons, factory crane lifting capacity ≥25 tons, and steel consumption per unit area ≥50kg/㎡. These specifications distinguish them from light steel structures, which feature thinner walls and smaller spans. The primary components include steel columns, steel beams, steel trusses, and gusset plates connected through welding and high-strength bolts.
Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction
Product Specifications & Technical Parameters
Structural Components
  • Load-bearing core components: Thick-walled H-beams/columns, box-section members, and heavy-duty steel trusses manufactured from high-strength steel (Q235, Q355B or higher) that bear the main vertical and horizontal building loads
  • Connecting and auxiliary components: High-strength bolts, welded joints, angle steel, U-beams, purlins, and support systems ensuring tight connections between main components and enhancing overall structural stability
  • Specialized supporting components: Customized elements including lifting beams for bridge cranes, lateral force bracing, and fireproof/corrosion-resistant coatings designed for specific working environments
Material Specifications
Items Specification
Material Q235B, Q355B galvanized or painted steel
Main frame H-section steel column & steel beam
Purlin C/Z-section steel purlin
Roof and wall Color-coated corrugated steel sheet, Rock Wool Sandwich Panels, EPS Sandwich Panels, Glass wool Sandwich Panels, PU sandwich panel
Door Rolling up door, Sliding door, Sandwich door/security door/PVC door
Window PVC /Steel or Aluminum Alloy frame window
Down spout Round PVC pipe
Industrial Applications
  • Manufacturing Plants: Ideal for metallurgy, chemical, and heavy industries requiring support for large equipment, resilience in harsh working conditions, and accommodation of bridge crane heavy-load requirements
  • Energy Infrastructure: Supporting structures for thermal power plants, wind power facilities, and other energy projects requiring high-intensity stress resistance and complex environmental adaptability
  • Transportation Hubs: Port facilities, railway freight stations, and logistics centers achieving large-span spaces to support efficient loading and unloading equipment operation
  • Specialized Buildings: Equipment platforms, silos, and other structures requiring exceptional load-bearing stability for specialized functions and demanding working conditions
  • Heavy-Duty Environments: Mining plants, earthquake-prone area buildings, and other challenging scenarios with custom designs ensuring structural safety and long-term operational reliability
Technical Support & Services
We provide comprehensive technical support and services for steel structure buildings. Our experienced technical team offers assistance with design, manufacturing, and installation processes. Our service portfolio includes design consultation, manufacturing services, on-site installation support, maintenance and repair services, and preventative maintenance programs.
Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction Multi Storey Heavy Steel Structure Building High Strength Heavy Metal Construction
